High temperature chamber kiln, 2200 °C, used - SOLD OUT(Article number: 2934)
|
Memo Inquiry |
||||||
Manufacturer: | deutscher Hersteller | ||||||
---|---|---|---|---|---|---|---|
Type: | HT 2200 | ||||||
Year of construction: | 2013 | ||||||
Description: | Dimensions (wxhxd) Outside: approx. 1400x2100x2000 mm Working space without retort: approx.180x180x200mm Usable volume: 8 liters Tmax (vacuum) 2200 °C Tmax (atmospheric pressure) 2200 °C ΔT (between 500 and 1500 ° C) according to DIN 17052 ± 10 K Max. heating rate (up to 2000 °C) 10 K / min Cooling time: 6 h Power requirements Power: 45 kW Power: 400 V Current: 115 A Backup fuse: 3x125 A Water supply / cooling water Cooling water: 40 l / min Entry temperature: max. 23 °C Required input pressure: max. 4 bar Output pressure: 0-2 bar Temperature difference between supply and return: 20 K Max. Chlorine content: 100 ppm Water hardness: 14 dH PH value: 7-9 Gas supply Gas type: Ar or N2 Flow rates: 200-2000 l / h Inlet pressure at the kiln: 10 bar Working pressure in the kiln (kiln clean, cold and empty) With two-stage rotary vane pump 5x10-2 mbar With turbopump 5x10-6 mbar Leak rate <5x10-4 mbar x l / s |
||||||
Quantity: | 1 Pc. | ||||||
Data in accordance with manufacturer | |||||||
